Features:
• CB / 10m Mobile antennas
• High power handling capability
• Tunable from 27 to 28.5 MHz
• Protection from static discharges DC-Ground
• 17/7 PH tapered stainless steel whip
• Supplied with special screw and anti-theft safety key
• 180° inclination and adjustable whip, detachable for car-wash
• Suitable for magnetic mount
Electrical Data:
• Type: CB base loaded
• Frequency range: 27-28.5 MHz
• Impedance: 50Ω unbalanced
• Radiation (H-plane): 360° omnidirectional
• Polarization: vertical
• Bandwidth at S.W.R. 2:1:
HI-POWER 3000: 1890 KHz
HI-POWER 4000: 2580 KHz
• S.W.R. at res. freq.: ≤ 1.2:1
• Max. power:
HI-POWER 3000: 400 Watts (CW) continuous, 1200 Watts (CW) short time
HI-POWER 4000: 600 Watts (CW) continuous, 1800 Watts (CW) short time
• Connector: UHF-male (PL 259)
Mechanical Data:
• Materials: Brass, Copper, Nylon, Stainless Steel
• Height (approx.):
HI-POWER 3000: 1740 mm
HI-POWER 4000: 2030 mm
• Weight (approx.): 450 gr
Manufacturer:
Name: Sirio Antenne
Adress: Via Liguria, 15, 46049 Volta Mantovana (MN) - Italien
Phone: +39 0376 801515
Email: info@sirioantenne.it
Web: https://www.sirioantenne.it/en/
